Beijing Yuchuang Qiji Technology Development Co., Ltd.
1 Years
| Ask Lasest Price | |
| Price : | Determine based on market prices |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Brand Name : | Huawei |
| Model Number : | 2298 V5 |
| Supply Ability : | /pieces >=2 pieces |
| Delivery Time : | 2-7 working days |
FusionServer 2298 V5 is a 2U, 2-socket rack server, applicable to services such as tiered storage of hot, warm, and cold data, and historical data archiving. With a highly efficient design, the server ensures excellent computing performance and provides flexible and ultra-large local storage scalability to reduce data storage costs. The 2U server can be configured with 2 Intel® Xeon® Scalable processors, 12 DDR4 DIMMs, and 24 x 3.5-inch plus four x 2.5-inch SAS/SATA disks for local storage, the FusionServer 2298 V5 supports a maximum of 4 NVMe SSDs. It incorporates patented technologies, such as Dynamic Energy Management Technology (DEMT)and Fault Diagnosis and Management (FDM), and integrates FusionDirector software for entire-lifecycle management, helping customers drive down OPEX and increase ROI.
| FusionServer 2298 V5 | |
| Internal Storage | Front: • 24 x 3.5-inch SAS/SATA HDDs, hot-pluggable, power-on/-off on a per HDD basis Rear: • 4 x 2.5-inch SAS/SATA/NVMe hard drives, hot-pluggable Flash storage: • 2 x M.2 SSDs |
| RAID Support | 4 rear SAS/SATA HDDs can be configured to support RAID 0, 1, 10, and 1E. RAID-level migration, disk roaming, self-diagnosis, and web-based remote configuration are supported |
| Network | • LOM: 2 x 10 GE + 2 x GE ports • Flexible Network Interface Card (NIC): 1 x OCP 2.0 standard NIC |
| PCIe Expansion | Up to 5 PCIe 3.0 expansion slots, including 1 PCIe card slot dedicated for the RAID controller card and 1 slot for flexible OCP 2.0 standard NIC |
| Power Supply | 2 hot-swappable PSUs, with support for 1+1 redundancy. Supported options include: • 900W AC Platinum PSUs (input: 100V to 240V AC, or 192V to 288V DC) • 1,500W AC Platinum PSUs − 1,000W (input: 100V to 127V AC) − 1,500W (input: 200V to 240V AC, or 192V to 288V DC) |
| Operating Temperature | 5°C to 35°C (41°F to 95°F), ASHRAE Class A3 compliant |
| Installation Kit | L-shaped guide rails and adjustable guide rails |
Management | • BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening • BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management • (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management |
|
|
