Beijing Yuchuang Qiji Technology Development Co., Ltd.
1 Years
| Ask Lasest Price | |
| Model Number : | R6515 |
| Price : | Contact us |
| Brand Name : | Dell Poweredge |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability : | /pieces >=2 pieces |
| Delivery Time : | 2-7 working days |
The Dell EMC PowerEdge R6525 Rack Server is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovations for dense compute environments to address traditional and emerging workloads and applications.
Deliver breakthrough performance, innovation and density for traditional and emerging workloads The new Dell EMC PowerEdge R6525 is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovation for dense compute environments. It’s ideal for traditional and emerging workloads and applications. High-level features include: • 64 processing cores and faster data transfer speeds with PCIe Gen 4 • Up to 3200MT/s memory speed to reduce latency and deliver faster response • Multi GPU support to accelerate end user VDI performance • Highest core count PE 1U server with cryptographic isolation between hypervisor and VMs Increase efficiency and accelerate operations with an automated infrastructure The Dell EMC OpenManage™ systems management portfolio delivers an efficient and comprehensive solution for PowerEdge servers through tailored, automated, and repeatable processes. • Automate server life cycle management with scripting via the iDRAC Restful API with Redfish conformance. • Simplify and centralize one to many management with the OpenManage Enterprise console. • Utilize the OpenManage Mobile app and PowerEdge Quick Sync 2 to easily manage servers using a phone or tablet. • Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus
| Processor | Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor |
| RAM | Up to 32 x DDR4 Maximum RAM RDIMM 2 TB LRDIMM 4TB Max Bandwidth up to 3200 MT/S |
| Controllers | PERC 10.5 – HBA345, H345, H745, H840, 12G SAS HBA PERC 11 – H755, H755N Chipset SATA/SW RAID (S150): Yes |
| Drive Bays | Front Bays Up to 4 x 3.5” hot plug SAS/SATA (HDD) Up to 8 x 2.5” hot plug SAS/SATA (HDD) Up to 12 x 2.5” (10 Front + 2 Rear) hot plug SAS/SATA/NVMe Optional Internal: 2 x M.2 (BOSS) Optional Rear: 2 x M.2 (BOSS-S2) |
| PSU | 800W Platinum 1400W Platinum 1100W Titanium |
Embedded mgmt iDRAC9 iDRAC RESTful API with Redfish iDRAC Direct Quick Sync 2 BLE/wireless module Bezel Optional LCD bezel or security bezel OpenManage™ SW OpenManage Enterprise OpenManage Enterprise Power Manager OpenManage Mobile Integrations & Connections OpenManage Integrations BMC Truesight Microsoft® System Center Redhat® Ansible® Modules VMware® vCenter™ OpenManage Connections IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager I Nagios® Core Nagios® XI Security Cryptographically signed firmware Secure Boot Secure Erase Silicon Root of Trust System Lockdown TPM 1.2/2.0, TCM 2.0 optional Embedded NIC 2 x 1 GbE LOM ports Networking Options (NOC) OCP x16 Mezz 3.0 + 2 x 1GE LOM GPU Options Up to 2 Single-Wide GPU | |
| PORTS | Front Ports: 1 x Dedicated iDRAC direct micro-USB 1 x USB 2.0 1 x VGA Rear Ports: 1 x Dedicated iDRAC network port 1 x Serial (optional) 1 x USB 3.0 1 x VGA |
PCIe 3 x Gen4 slots (x16) at 16GT/s Operating Systems & Hypervisors Canonical® Ubuntu® Server LTS Citrix® HypervisorTM Microsoft® Windows Server® with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® OEM-ready version available From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com/OEM. Recommended support Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visit Dell.com/ServiceDescriptions Recommended services ProSupport Plus with SupportAssist provides proactive and predictive support for critical systems. ProSupport provides comprehensive hardware and software support. Get more from your technology starting on day one with ProDeploy Enterprise Suite deployment offers. For more information, visit Dell.com/Services. |
Figure 1. Front view of the 10 x 2.5-inch drive system 1. Left control panel 2. VGA port 3. Right control panel 4. Information tag 5. Drive (10)
Figure 2. Front view of the 8 x 2.5-inch drive system 1. Left control panel 2. Drive (8) 3. Right control panel 4. VGA port 5. Information tag
Figure 3. Front view of the 4 x 3.5-inch drive system
1. Left control panel 2. Drive (4) 3. VGA port 4. Right control panel 5. Information tag
Figure 4. Rear view of the 10 x 2.5-inch drive system 1. Power supply unit (PSU 1) 2. PCIe expansion card riser (slot 1) 3. PCIe expansion card riser (slot 2) 4. USB 2.0 port (1) 5. Power supply unit (PSU 2) 6. VGA port 7. USB 3.0 port (1) 8. iDRAC dedicated port 9. System identification button 10. OCP NIC port (optional) 11. NIC port (2) 12. BOSS S2 card (optional)
Figure 7. Inside the system 1. Drive backplane 2. Rear mounting front PERC module 3. Dual fan module (4) 4. System board 5. Memory DIMM socket for processor 2 (B1) 6. Heat sink for processor 2 7. Riser 3 8. Intrusion switch 9. Power supply unit (PSU 2) 10. Power supply unit (PSU 1)
|
|
