The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R640 is simply managed, freeing up time for high profile projects.
• Simplify management with the OpenManage Enterprise™ console, with customized reporting and automatic discovery.
• Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet
| R630 | Technical Specification | |
| Processor | Intel® Xeon® processor E5-2600 v4 product family | |
| Memory | Up to 1.5TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB DDR4 up to
2400MT/s | |
Cache | 2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18, 22 | |
| Form factor | 1U rack server | |
| Drive bays | Internal hard drive bay and hot-plug backplane: Up to 24 x 1.8" SATA SSD Up to 10 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, Up to
4 NVMe PCIe Up to 8 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA | |
| Chipset | Intel C610 series chipset | |
| Dimensions | 24 x 1.8" and 10 x 2.5" drive configuration: H: 4.28 cm (1.68 in), W: 48.23 cm (18.98 in), D: 75.51 cm (29.72 in) 8 x 2.5" drive configuration: H: 4.28 cm (1.68 in), W: 48.23 cm (18.98 in), D: 70.05 cm (27.57 in) | |
| I/O slots | Up to 3 x PCIe 3.0 slots plus dedicated PERC slot | |
| RAID controllers | Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730,
PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA | |
| Maximum internal storage | HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, NVMe PCIe 24 x 1.8" SSD – up to 23TB via 0.96 TB hot-plug SATA SSD 10 x 2.5" – up to 18TB via 1.8TB hot-plug SAS HDD 8 x 2.5" – up to 14TB via 1.8TB hot-plug SAS HDD | |
| Power supplies | Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W | |
The R630 has three chassis options: 8 x 2.5” drives, 10 x 2.5” drives or 24 x 1.8” drives. A chassis cannot be reconfigured or upgraded after point of purchase. Other features on the front panel include an interactive LCD control panel, USB management port, video connector and vFlash media card slot.
Figure 1 is the front view of the R630 chassis with 8 x 2.5” hard drives.
Figure 1. 8-drive bay chassis front view without bezel
Figure 2 is the front view of the R630 chassis with 10 x 2.5” hard drives.
Figure 2. 10-drive bay chassis front view without bezel
Figure 3 is the front view of the R630 chassis with 24 x 1.8” hard drives.
Figure 3. 24-drive bay chassis front view without bezel
Figure 4 shows the optional bezel on the front of an 8-drive bay chassis. The bezel for the 10-drive bay chassis is different than the bezel for the 8-drive bay chassis.
Figure 4. Front view with bezel
Figure 5 shows the R630 back panel of the 8-drive bay chassis with 3 PCIe slots. Features on the back panel include the system identification light and button, iDRAC8 Enterprise port (activated only when iDRAC8 Enterprise is installed), serial connector, video connector, USB connectors, Ethernet connectors and power supplies.
Figure 5. Back view
Figure 6 is an internal view of the R630 24-drive bay system including fans, DIMMs, power supplies, system board and hard drive bays.
Figure 6. 24-drive 1.8” bay chassis internal view
|
|
